Series 600 – Wide Target Foot Switch


Available in single and two stage operation.

Designed with a stable platform for Greater Operator Comfort and Improved Productivity!

Standard snap switch rating: 10 AMP, 125/250 VAC

Another foot switch designed with the operator in mind. Unlike traditional foot switches, the Series 600 has a wider platform with support along the front operating edge and around the corners to deter tipping.

Download/Print Series 600 Flyer

SKU: N/A Categories: , ,



  1. The 600 features a flexible strain relief option for up to 18/3 SVT cord for longer cable life
  2. High strength socket head hinge screws
  3. All threaded openings are extruded to provide extra thread engagement
  4. Stable platform, even on corners!
  5. Long life snap switch
  6. #8 grounding screw is provided
  7. High quality, black E-coat
  8. A fiberglass sleeve is supplied to comply with UL requirements for strain-relief of thermoplastic jacketed cord
  9. Wide target area!


Item #List PriceDescription Cord SetDimensionsWeight
600-1990-20$30.85Single Switch with cord set8' 24/2 cable with leads strippedL 3 1/2" x W 4"x H 1.2"1 lb.
600-6990-20$39.662-Stage Operation Foot Switch with cordset8' 22/4 black cable with leads strippedL 3 1/2" x W 4"x H 1.2"1 lb. 2 oz.

Additional information

Weight 16 oz
Item #

600-1990-20, 600-6990-20
